1. Front / rear / left / right camera switch
When the engine starts, the system activates the front camera to verify operation for 8 seconds, then turns it off.
2. Automatic rear view:
When reverse gear is engaged, the system is activated as is the rear view camera. When reverse gear is removed, it switches to the front camera for 7 seconds and then turns off.
3. The front view always activates the mode:
Pressing the included control switch also activates the video of the front camera or lateral cameras.
In this mode, the system will control and activate the front or lateral cameras at all times.
Pressing the control switch again deactivates the system.
Priority of operation: rear view and then front view
Maximum power: 50 ma, 12 v.
System signal: PAL / NTSC
Operating temperature: -20 ° to 80 ° C
Front view camera: Activation when reverse gear is removed or by pressing the remote control.
Rear view camera: Activation when reverse gear is engaged or by pressing the remote control.
Lateral cameras: Activation when turn light is engaged or by pressing the remote control.
